12V 5.4A 65W Bare Board LED/LCD/CCTV/Medicial Switching Power Supply AC to DC
Feature:
. Input Voltage:90-264V
. Maximum output:65W
. Output over current protection
. Output over voltage protection
. Over Temperature Protection
. Output Short Circuit Protection
. 100% full load burn-in test
Technical Parameters:
Why Choose US:
1.More than 6 years experience of power supply manufacturer.
2.Professional team for after-sale service 7*24.
3.Experienced R & D team and profesional sales team.
4.Offer OEM & ODM service, we will evaluate, design and produce your customized products.
5.Offer confidentiality agreement.
6.Meet the safety requirements of various countries.
7.Meet the environmental protection RoHS requirements of various countries.
8.Meet the requirements of conducting radiation (EMC/EMI) of various countries.
9.With CB, UL, FCC, CE, GS, EMC, PSE, SAA, KC ,BSMI,CCC, S-MARK,UC ,RoHS and Reach certificates.
If you have any questions, please feel free to contact us.
FAQ
Q1.What type of company are you?
A1.We are a comprehensive enterprise integrating industry and trade with a professional factory and RISUNIC brand.
Q2.Can l ask for samples before placing an order?
A2:Yes,we welcome sample order to test and check quality.Mixed samples are acceptable.
Q3.How do you ship my cargoes and how long does it take to deliver?
A3:We usually ship your cargoes by express.And it usually takes 1-3 days if you buy our regular products with regular QTY. If you buy the customized products,it needs 7-10days.Please be patient,we willtrack the latest delivery information and inform you.
Q4.What need l do if l want to print my own logo?
A4: First,please send us your logo file in high resolution.We will make some drafts for your reference to confirm the
position and size of your logo.Next we will make 1-2 samples for you to check the actual effect.Finally the formal production will start after the sample confirmed.
Q5.Can we make customized color?
A5:Yes,we can make any color for cable according to the Pantone Color Number.
Q6.What is the warranty of your products?
A6:We offer the warranty of 12 months for all products.
Feature:
. Input Voltage:90-264V
. Maximum output:65W
. Output over current protection
. Output over voltage protection
. Over Temperature Protection
. Output Short Circuit Protection
. 100% full load burn-in test
Technical Parameters:
| Input Characteristics | |||
Parameter | Technical Requirement | Unit | Remark |
| Rated input voltage | 220V | Vac | |
| Input Voltage Range | 90-264V | Vac | |
| Input Voltage Frequency | 47 ~ 63 | Hz | 50 or 60Hz |
| Input power | 0.3 | W | No load |
| Input power factor | / | ||
| / | |||
| Maximum Input Current | 1.8 | A | Vin=115Vac rated load |
| A | Vin=230Vac rated load | ||
| Efficiency | ≥ 85 % | Vin=115Vac rated load | |
| ≥ 85 % | Vin=230Vac rated load | ||
| Inrush Current | 100 | A | 115Vac and 230Vac cold start |
| Output Characteristics | |||
| Parameter | Technical Requirement | Unit | Remark |
| Rated Output Voltage | 12V | Vdc | rated load |
| Output Voltage Range | 12V±5% | Vdc | No load |
| Output Current Range | 0-5.4 | A | |
| Rated Output Power | 65 | W | |
| Voltage regulation rate | ±5% | ||
| Load regulation rate | ±5% | ||
| Turn-On/Off Overshoot | ≤10% | ||
| Ripple & Noise | 120 | mVp-p | Apply the cap 0.1uF and 47uF in parallel with output terminal for measurements. And set the oscilloscope bandwidth 20MHZ. |
Why Choose US:
1.More than 6 years experience of power supply manufacturer.
2.Professional team for after-sale service 7*24.
3.Experienced R & D team and profesional sales team.
4.Offer OEM & ODM service, we will evaluate, design and produce your customized products.
5.Offer confidentiality agreement.
6.Meet the safety requirements of various countries.
7.Meet the environmental protection RoHS requirements of various countries.
8.Meet the requirements of conducting radiation (EMC/EMI) of various countries.
9.With CB, UL, FCC, CE, GS, EMC, PSE, SAA, KC ,BSMI,CCC, S-MARK,UC ,RoHS and Reach certificates.
If you have any questions, please feel free to contact us.
FAQ
Q1.What type of company are you?
A1.We are a comprehensive enterprise integrating industry and trade with a professional factory and RISUNIC brand.
Q2.Can l ask for samples before placing an order?
A2:Yes,we welcome sample order to test and check quality.Mixed samples are acceptable.
Q3.How do you ship my cargoes and how long does it take to deliver?
A3:We usually ship your cargoes by express.And it usually takes 1-3 days if you buy our regular products with regular QTY. If you buy the customized products,it needs 7-10days.Please be patient,we willtrack the latest delivery information and inform you.
Q4.What need l do if l want to print my own logo?
A4: First,please send us your logo file in high resolution.We will make some drafts for your reference to confirm the
position and size of your logo.Next we will make 1-2 samples for you to check the actual effect.Finally the formal production will start after the sample confirmed.
Q5.Can we make customized color?
A5:Yes,we can make any color for cable according to the Pantone Color Number.
Q6.What is the warranty of your products?
A6:We offer the warranty of 12 months for all products.
