6-layer HDI PCB, multi-layer PCB and Enig PCB factories provide multi-layer PCB circuit boards

6 layer HDI PCB, multilayer PCB with ENIG PCB Factory Offers Multilayer PCB Circuit BoardsFeatures-Our Products Advantage  1. Over 10 years experience manufacturer in PCBA service field. 2.  Big scale of producing makes sure that your purchase cost is lower. 3. Advanced production line guarantees st

Featured Products

6 layer HDI PCB, multilayer PCB with ENIG PCB Factory Offers Multilayer PCB Circuit Boards

Features-Our Products Advantage

1. Over 10 years experience manufacturer in PCBA service field.

2.  Big scale of producing makes sure that your purchase cost is lower.

3. Advanced production line guarantees stable quality and long life span.

4. Design and produce almost any PCB as your requirement.

5. 100% test for all customized pcb products

6. One-stop Service ,we can help to purchase the compnents



Can we see other PCBs?

6 Layer HDI PCB, Multilayer PCB with Enig PCB Factory Offers Multilayer PCB Circuit Boards




Can we know your factory PCB manufacture capability?



PCB  Manufacture  Capability
Item   Manufacture  Capability
Layers   1-26  Layers
HDI 2+N+2
Material  Types Fr-4,   Fr-5,   High-Tg,   Aluminum  Based  , Halogen  Free,
Isola,   Taconic,   Arlon,   Teflon,   Rogers,
Max.   Panel  Dimension39000mil  *  47000mil  (1000mm  *  1200mm)
Outline  Tolerance ± 4mil  (± 0.10mm)
Board  Thickness8mil-236mil  (0.2  -  6.0mm)
Board  Thickness  Tolerance ± 10%
Dielectric  Thickness 3mil-8mil  (  0.075mm-0.20mm)
Min.   Track  Width 3mil  (  0.075mm  )
Min.   Track  Space3mil  (  0.075mm  )
External  Cu  Thickness 0.5  OZ  -  10  OZ  (  17um  -  350um)
Internal  Cu  Thickness   0.5OZ  -  6OZ  (  17um  -  210um)
Drilling  Bit  Size  (  CNC  ) 6mil-256mil  (  0.15mm  -  6.50mm)
Finished  Hole  Dimension       4mil-236mil(0.1mm  -  6.0mm)
Hole  Tolerance± 2mil  (± 0.05mm)
Laser  Drilling  Hole  Size   4mil(0.1mm)
Aspect  Ration 16: 1
Solder  MaskGreen,   Blue,   White,   Black,   Red,   Yellow,   Purple,   etc.
Min  Solder  mask  Bridge2mil(0.050mm)
Plugged  Hole  Diameter8mil-20mil  (  0.20mm-0.50mm)
Beveling30o  -  45o
V-scoring+/-0.1mm,   15o    30o    45o    60o
Impedance  Control                               Min. 5%    General  ± 10%
Surface  Finishing HASL,   HASL(lead  Free),   Immersion  Gold
Immersion  Silver,   OSP,   Hard  Gold  (  up  to  100u" )
CertificationUL  RoHS  ISO9001: 2000  ISO14000: 2004  SGS
TestingFlying  probe, E-TEST,   X-RAY  Inspection  , AOI
FilesGerber  Protel  DXP  Auto  CAD  PADS  OrCAD  Express  PCB  etc





Can You Show some Pictures of  the PCB factory?

6 Layer HDI PCB, Multilayer PCB with Enig PCB Factory Offers Multilayer PCB Circuit Boards



How to pay and how to ship?

6 Layer HDI PCB, Multilayer PCB with Enig PCB Factory Offers Multilayer PCB Circuit Boards




FAQ


Q1: What's your minimum order quantity?

A1: No MOQ , 1 pcs is accepted .



Q2: what file we should offer?

A2: PCB:Gerber file is better,( Protel ,power pcb,PADs file), PCBA : Gerber file and BOM list.



Q3:No PCB file/Gerber file, only have the PCB sample,can you produce it for me?

A3: Yes, we could help you to clone the PCB. Just send the sample PCB to us, we could clone the PCB layout and work out the PCB files, then produce for you.



Q4: What is the lead time?

A4:Sample needs 7-10 days, mass production needs 10- 15 days,

according to the order volume.Also we can provide quick time service 1-2days.



Q5: What payment terms do you have?

A5: For small orders, we usually prefer Paypal and Western Union; For bigger order,pls pay by TT.

6 Layer HDI PCB, Multilayer PCB with Enig PCB Factory Offers Multilayer PCB Circuit Boards


Would like to know more about the product? Send us inquiry, click "Send" now!

Please feel free to send us gerber file for lastest price and discount!



Contact Person: Kitty Ho







Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
