Metal/PCB high precision CNC fiber laser cutting machine

Products Description:The self-developed software can directly connecting information system of our customer. Marking input information can not only generated automatically by software, but also be received through network. It can be integrated with SMT online operation and automatic off-board workstation.Comparing with label and

Featured Products

Products Description:
The self-developed software can directly connecting information system of our customer. Marking input information can not only generated automatically by software, but also be received through network. It can be integrated with SMT online operation and automatic off-board workstation.

Comparing with label and printing, laser marking can record PCB information by marking serial number and barcode for quality control of electronic product. PCB Laser Marking Machines in  different types are suitable for PCB marking of large area and  irregular shape board or thin plate as well as multi-marking on one-side or multi-board in high efficiency and speed.High Precision CNC Fiber Laser Cutting Machine for Metal/PCB

PCB Laser Marking Machine

  LCA10/30C-S3LCA10/30C-S5LCB10/30C-S5LCB10/30C-D5
 laser sourceCO2/FiberCO2/FiberCO2/FiberCO2/Fiber
Laserlaser wave length 10600nm/1064nm10600nm/1064nm10600nm/1064nm10600nm/1064nm
Output Power 30±0.5W10±0.5W10±0.5W30±0.5W
Processability processing area300mm*300mm500mm×500mm500mm×500mm500mm×500mm
 Repositioning resolution±0.1mm±0.1mm±0.1mm±0.1mm
Min. Line Width<0.15mm<0.1mm<0.1mm<0.15mm
Min. Character Height<0.3mm<0.2mm<0.2mm<0.3mm
ConfigurationWorking Table Turn-over mechanics X-Y linear moduleX-Y linear moduleX-Y linear module
Positioning System paraxial  CCD cameraparaxial  CCD cameraparaxial  CCD cameraparaxial  CCD camera
Control System IPCIPCIPCIPC
 auxiliary control system Mitsubishi PLCMitsubishi PLCMitsubishi PLCMitsubishi PLC
External auxiliary deviceNegative pressure suction dust-exhaust systemNegative pressure suction dust-exhaust systemNegative pressure suction dust-exhaust systemNegative pressure suction dust-exhaust system
Operating Conditionsvoltage 220V220V380V380V
frequency 50KHz50KHz50KHz50KHz
Capacity 3KVA2.5KVA6KVA5KVA
phase 2233
operating temperature 15-30ºC15-30ºC15-30ºC15-30ºC
operating humidity<50%<50%<50%<50%
Equipment Size700mm×1300mm×1700mm1500mm×1740mm×1900mm1700mm×1400mm×1500mm2300mm×1900mm×1600mm
1. High-performance CO2 / Fiber laser has high-quality laser beam, small focusing spots and well-distributed power.
2. The high-pixel CCD camera makes automatic positioning, identification and feedback reporting come true.
3. Gantry structure and synchronous transmission guideways ensure the stable and precision performance.
4. The function of automatic focusing and track width adjusting are designed to match up different production line.

Position Accuracy: ±0.1mm
Min. Line Width:  <=0.1mm
Laser Source: CO2/Fiber ( optional )
Processing Area: 500mm*500mm
Equipment Size: 1700mm*1400mm*1500mm
Equipment Features:
  Work offline or online by cooperating with upper and lower board equipment;
  Multi-board and multi-position marking by X/Y servo Module ;
  Front and back marking to increase work efficiency .
Application: High efficiency and speed large area PCB marking

Double-head Double-Station PCB Laser Marking Machine   LCB 10/30C - D5

Position Accuracy: ±0.1mm
Min. Line Width: <=0.12mm
Laser Source: CO2/Fiber ( optional )
Processing Area: 500mm*500mm
Equipment Size: 2300mm*1900mm*1600mm
Equipment Features:
Loading and unloading simultaneously by double working station and two-way movement of upper and lower board ;Front and back marking to increase work efficiency ;No damage to PCB by adopting vacuum absorption technique ;Offline work is optional
Application: irregular shape board or thin plate marking

Dynamic Focusing PCB Laser Marking Machine  LCA 10/30C -S3

Position Accuracy: ±0.1mm
Min. Line Width:  <=0.12mm
Laser Source: CO2/Fiber ( optional )
Processing Area: 300mm*300mm
Equipment Size: 700mm*1300mm*1700mm
Equipment Features:
Dynamic Focusing Marking system to ensure large area processing without mechanical movement ;
Turn-over mechanics to ensure front and back marking and compact size suitable for online production .
Application: Multi-marking on one-side or multi-board marking
High Precision CNC Fiber Laser Cutting Machine for Metal/PCB
High Precision CNC Fiber Laser Cutting Machine for Metal/PCB

High Precision CNC Fiber Laser Cutting Machine for Metal/PCB
Company Introduction:
High Precision CNC Fiber Laser Cutting Machine for Metal/PCB


High Precision CNC Fiber Laser Cutting Machine for Metal/PCB

Wuhan Huagong Laser Engineering Co.,Ltd is one of the largest laser equipment manufacturers in China. HGLASER is the main subsidiary company of Huagongtech Co., Ltd. (Stock code: 000988)

HGLASER is a national key high-tech enterprise, possessing technology centers and provincial key laboratories. Relying on the National Engineering Research Center for Laser Processing, National Key Laboratory for Laser Technology and Exhibition Center for Laser Technology Processing, HGLASER undertakes national key projects and scientific research projects.

High Precision CNC Fiber Laser Cutting Machine for Metal/PCB

High Precision CNC Fiber Laser Cutting Machine for Metal/PCB
Wuhan Huagong Laser Engineering Co.,Ltd possesses HGLASER and FARLEY?LASERLAB two famous brands. HGLASER has always been committed to providing broad and comprehensive laser manufacturing solutions in industrial manufacturing field, researching, manufacturing and selling various laser processing and plasma machining equipments, providing tube laser cutting processing and oil pipeline trade services. The main products of HGLASER cover the full power series of laser cutting systems, laser welding systems, laser marking series, laser texturing equipments, laser heat treatment systems, laser drilling machines, laser devices, all kinds of support devices, laser processing and plasma machining equipments, which are used widely in metallurgy, non-ferrous metals, automobiles, parts, aviation, military, precision instruments, machine manufacturing, hardware, integrated circuits, semiconductor manufacturing, solar, education, communication and measurement, packaging, leathers, plastics, rubbers, jewelries, crafts, medical equipments, etc.

High Precision CNC Fiber Laser Cutting Machine for Metal/PCB

FAQ:
Q1 :How about warranty?
A1:3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.

Q2: I don't know which one is suitable for me ?
A2:Please tell me your
1) Max work size:We can do work size with 110*100mm-----300mm*300mm.
2) Materials and marking effect:we will check whether our machine is suitable for you or not and choose a most suitable power and optional parts.

Q3:Payment terms?
A3:TT/West Union/Payple/LC/Cash and so on.

Q4:Do you have CE document and other documents for customs clearance?
A4:Yes,we have Original. At first we will show you and And after shipment we will give you CE/Packing list/Commercial Invoice/Sales contract for customs clearance.

Q5:I don't know how to use after i receive Or i have problem during use,how to do?
A5:
1) We have detailed user manual with pictures and CD,you can learn step by step.
2) If have any problem during use,you need our technician to judge
The problem elsewhere will be solved by us. We can provide team viewer

Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide Door service if you need.
