High weatherproof selective absorbing film flat plate solar water heater
| Name | Specification | PJF-150L | PJF -200L | PJF -300L |
| Flat plate collector | Quantity ( pc ) | 1 | 1 | 2 |
| Collector dimension(mm) | 2000x1000x80mm | 2000x1250x80mm | 2000x1000x80mm | |
| Header tube(mm) | Φ22 x0.6mm | |||
| Riser Tube(mm) | Φ10*0.5mm | |||
| Integrated circulation Pipe | Corrugated Pipe | |||
| Welding | Laser welding | |||
| Absorber coating | Black Coating | |||
| Insulation material | Fiber glass + polyester fiber | |||
| Material | 3.2mm Low iron tempered textured glass | |||
| The rated pressure | 0.6MPa | |||
| Frame color | Silver/Black | |||
| Water Tank | Insulation | Polyurethane in 50mm | ||
| Inner tank | Food grade stainless steel, SUS304-2B, 1.2mm thickness | |||
| The rated pressure | <0.6MPa | |||
| Electrical Heater | 1.5KW | |||
| Outside material | Galvanized steel plate, 0.4mm thickness | |||
| Support | Material | Glavanized Plate with Powder Coating | ||
| Spare Parts | Material | safty valve, check valve and magnisium bar, electric element | ||
Solar water heater picture
Package picture
