Printed Circuit Boards Metal Core Aluminum Copper Cladding Laminate Offcuts Printed Circuit Board
Products Information
FR4 copper clad,use glass fiber cloth as substrate material, immersed with epoxy resin, bake into prepreg sheet, combined several prepreg sheets single side or double sides with copper foil, hot pressing, curing, then forming CCL.
FR-4 copper clad laminated sheet uses glass fiber cloth as substrate material. After being immersed with epoxy resin and then baked into prepreg sheet, several prepreg sheets are then coated with copper foil on one side or both sides, and CCL is finally formed by hot pressing and curing.
FR-4 copper clad laminated sheet has excellent thermal stability and machinability, widely used in the manufacture of printed circuit board (PCB) for television sets, computers, communications equipment and other electronic products.
It is a kind of copper foil covered laminated board formed through heat pressing after the electric industry alkali-free glass fiber dips into thermoset epoxy resins and is covered with copper foil at one side or both sides, called copper-clad laminate(CCL) .It is used for production of printed circuit board(PCB).
Apllication
Products Show
Company Information
Xuchang Ruiyuan insulation material co.,ltd insist on the
idea " GOOD QULAITY, GOOD SERVICE ". it is establish 20years old.
It is located in Xuchang City, Henan Province, China. From 2010 year old our company begin deal international trade, based on the original business. Till now we import and export to many contries, such as United Kingdom, Germany, France, Ukrain, Bulgaria, Italy, India, Pakistan, Bangladesh, Korea, Brzil and so on.
Our manufacturing technique is leading in this field and well known in the world. Now there are more than 20 product facilities, and 105 staff, including 5 senior technical, 20 intermediate technical. Main products are manufactured on international standard.
Our products mainly used for transformer and electrical motor, we produces insulation paper, insulation board, insulation tape,insulation film and also sales PTFE FR4 PA6 and cable wire.
We will develop with you by best-quality products, warm-hearted service and mutually beneficial cooperation!
Package and Shipping
Service
Products Information
FR4 copper clad,use glass fiber cloth as substrate material, immersed with epoxy resin, bake into prepreg sheet, combined several prepreg sheets single side or double sides with copper foil, hot pressing, curing, then forming CCL.
| Item | Unit | Value | Typical value | |
| Copper foil peel streng | 125ºC | N/mm | ≥0.7 | 1.5 |
| Float288ºC/10sec | ≥1.05 | 1.65 | ||
| Thermal stress (float288ºC/unetched) | sec | ≥10 | 120 | |
| Warpage (without treatment) | % | ≤1.0 | 0.20 | |
| Flammability | - | V-0 | V-0 | |
| Vitrification transition temperature | ºC | ≥130 | 138 | |
| Surface resistivity (35ºC air) | MΩ | ≥1.0*104 | 1.0*106 | |
| Volume resistivity(35ºC air) | MΩ/cm | ≥1.0*106 | 1.0*108 | |
| Dielectric constant(1MHz) | - | ≤5.5 | 5.0 | |
| Dielectric loss factor (1MHz) | - | ≤0.035 | 0.024 | |
| Arc resistance | sec | ≥60 | 120 | |
FR-4 copper clad laminated sheet uses glass fiber cloth as substrate material. After being immersed with epoxy resin and then baked into prepreg sheet, several prepreg sheets are then coated with copper foil on one side or both sides, and CCL is finally formed by hot pressing and curing.
FR-4 copper clad laminated sheet has excellent thermal stability and machinability, widely used in the manufacture of printed circuit board (PCB) for television sets, computers, communications equipment and other electronic products.
It is a kind of copper foil covered laminated board formed through heat pressing after the electric industry alkali-free glass fiber dips into thermoset epoxy resins and is covered with copper foil at one side or both sides, called copper-clad laminate(CCL) .It is used for production of printed circuit board(PCB).
| Material | Fiberglass, epoxy resin |
| Sheet thickness | 0.1-3.2mm |
| Color | UV, Non-UV |
| Rated voltage | 40KV |
| Tensile strength | Excellent |
| Size | 37" x 49", 41" x 49", 43" x 49" . |
| Copper thickness | 12μm,15μm,18μm,25μm,28μm,35μm,70μm, as requested. |
| Features | 1.TG: 135±5ºC(DSC). 2.UV Blocking and AOI compatible. 3.Good thermal resistance performance. 4.Excellent dimensional stability. 5.Excellent mechanical and electrical propertles. |
| Applications | Computers, instruments, cameras, communication, equipment, electronic game machine, televisions, etc. |
Apllication
Products Show
Company Information
Xuchang Ruiyuan insulation material co.,ltd insist on the
idea " GOOD QULAITY, GOOD SERVICE ". it is establish 20years old.
It is located in Xuchang City, Henan Province, China. From 2010 year old our company begin deal international trade, based on the original business. Till now we import and export to many contries, such as United Kingdom, Germany, France, Ukrain, Bulgaria, Italy, India, Pakistan, Bangladesh, Korea, Brzil and so on.
Our manufacturing technique is leading in this field and well known in the world. Now there are more than 20 product facilities, and 105 staff, including 5 senior technical, 20 intermediate technical. Main products are manufactured on international standard.
Our products mainly used for transformer and electrical motor, we produces insulation paper, insulation board, insulation tape,insulation film and also sales PTFE FR4 PA6 and cable wire.
We will develop with you by best-quality products, warm-hearted service and mutually beneficial cooperation!
Package and Shipping
Service
