6-layer high Tg circuit board PCB factory PCB board

ItemRIGIDFLEXRIGID-FLEXMax Layer60L8L36LInner Layer Min Trace/Space3/3mil3/3mil3/3milOut Layer Min Trace/Space3/3mil3.5/4mil3.5/4milInner Layer Max Copper6oz2oz6ozOut Layer Max Copper6oz2oz3ozMin Mechanical Drilling0.15mm0.1mm0.15mmMin Laser Drilling0.1mm0.1mmItemRIGIDFLEXRIGID-FLEX0.1mmAspect Ratio(Mechanical Drilling)20:110:11

Featured Products


6 Layers High Tg Circuit Board PCB Factory PCB Board
6 Layers High Tg Circuit Board PCB Factory PCB Board6 Layers High Tg Circuit Board PCB Factory PCB Board
ItemRIGIDFLEXRIGID-FLEX
Max Layer60L8L36L
Inner Layer Min Trace/Space3/3mil3/3mil3/3mil
Out Layer Min Trace/Space3/3mil3.5/4mil3.5/4mil
Inner Layer Max Copper6oz2oz6oz
Out Layer Max Copper6oz2oz3oz
Min Mechanical Drilling0.15mm0.1mm0.15mm
Min Laser Drilling0.1mm0.1mmItemRIGIDFLEXRIGID-FLEX0.1mm
Aspect Ratio(Mechanical Drilling)20:110:112:1
Aspect Ratio(Laser Drilling)1:1/1:1
Press Fit Hole Ttolerance±0.05mm±0.05mm±0.05mm
PTH Tolerance±0.075mm±0.075mm±0.075mm
NPTH Tolerance±0.05mm±0.05mm±0.05mm
Countersink Tolerance±0.15mm±0.15mm±0.15mm
Board Thickness0.4-8mm0.1-0.5mm0.4-3mm
Board Thickness Tolerance(<1.0mm)±0.1mm±0.05mm±0.1mm
Board Thickness Tolerance(≥1.0mm)±10%/±10%
Impedance ToleranceSingle-Ended:±5Ω(≤50Ω),±7%(>50Ω)Single-Ended:±5Ω(≤50Ω),±10%(>50Ω)Single-Ended:±5Ω(≤50Ω),±10%(>50Ω)
Differential:±5Ω(≤50Ω),±7%(>50Ω)Differential:±5Ω(≤50Ω),±10%(>50Ω)Differential:±5Ω(≤50Ω),±10%(>50Ω)
Min Board Size10*10mm5*10mm10*10mm
Max Board Size22.5*30inch9*14inch22.5*30inch
Contour Tolerance±0.1mm±0.05mm±0.1mm
Min BGA7mil7mil7mil
Min SMT7*10mil7*10mil7*10mil
Surface TreatmentENIG,Gold Finger,Immersion Silver,Immersion Tin,HASL(LF),OSP,ENEPIG,Flash Gold;Hard gold platingENIG,Gold Finger,Immersion Silver,Immersion Tin,HASL(LF),OSP,ENEPIG,Flash Gold;Hard gold platingENIG,Gold Finger,Immersion Silver,Immersion Tin,HASL(LF),OSP,ENEPIG,Flash Gold;Hard gold plating
Solder MaskGreen,Black,Blue,Red,Matt GreenGreen Solder Mask/Black PI/Yellow PIGreen,Black,Blue,Red,Matt Green
Min Solder Mask Clearance1.5mil3mil1.5mil
Min Solder Mask Dam3mil8mil3mil
LegendWhite,Black,Red,YellowWhite,Black,Red,YellowWhite,Black,Red,Yellow
Min Legend Width/Height4/23mil4/23mil4/23mil
Strain Fillet Width/1.5±0.5mm1.5±0.5mm
Bow & Twist0.3%/0.05%
