Custom 4 layer flex rigid & flexible pcb cable manufacture FR4 pcba manufacturer As below specification for reference:ItemProcess CapabilityLayer Counts1-24LMaterialFR-4, Ceramic, Alu Base ,Cu base. Rogers etcMaximum Size600mm X 1500mmBoard Outline Tolerance±0.10mmBoard Thickness0.20mm--8.00mmThickness Toler

Featured Products

Custom 4 layer flex rigid & flexible pcb cable manufacture FR4 pcba manufacturer

 As below specification for reference:

ItemProcess Capability
Layer Counts1-24L
MaterialFR-4, Ceramic, Alu Base ,Cu base. Rogers etc
Maximum Size600mm X 1500mm
Board Outline Tolerance±0.10mm
Board Thickness0.20mm--8.00mm
Thickness Tolerance( t≥0.8mm)±8%
Thickness Tolerance( t<0.8mm)±10%
Insulation Layer Thickness0.075mm--5.00mm
Minimum Line0.075mm
Minimum Space0.075mm
Out Layer Copper Thickness18um--350um
Inner Layer Copper Thickness17um--210um
Drilling Hole (Mechanical)0.15mm--6.35mm
Finish Hole (Mechanical)0.10mm--6.30mm
Diameter Tolerance (Mechanical)0.05mm
Registration (Mechanical)0.075mm
Aspect Ratio16:1
Solder Mask TypeLPI
SMT Mini. Solder Mask Width0.075mm
Mini. Solder Mask Clearance0.05mm
Plug Hole Diameter0.25mm--0.60mm
Impedance Control Tolerance±10%
Surface FinishHASL,ENIG,Chem. Tin,Chem Silver. Flash Gold,OSP,Gold finger
