PCB Manufacture Capability:
| PCB Manufacture Capability | |
| Item | Manufacture Capability |
| Layers | 1-26 Layers |
| HDI | 2+N+2 |
| Material Types | Fr-4, Fr-5, High-Tg, Aluminum Based , Halogen Free, |
| Isola, Taconic, Arlon, Teflon, Rogers, | |
| Max. Panel Dimension | 39000mil * 47000mil (1000mm * 1200mm) |
| Outline Tolerance | ± 4mil (± 0.10mm) |
| Board Thickness | 8mil-236mil (0.2 - 6.0mm) |
| Board Thickness Tolerance | ± 10% |
| Dielectric Thickness | 3mil-8mil ( 0.075mm-0.20mm) |
| Min. Track Width | 3mil ( 0.075mm ) |
| Min. Track Space | 3mil ( 0.075mm ) |
| External Cu Thickness | 0.5 OZ - 10 OZ ( 17um - 350um) |
| Internal Cu Thickness | 0.5OZ - 6OZ ( 17um - 210um) |
| Drilling Bit Size ( CNC ) | 6mil-256mil ( 0.15mm - 6.50mm) |
| Finished Hole Dimension | 4mil-236mil(0.1mm - 6.0mm) |
| Hole Tolerance | ± 2mil (± 0.05mm) |
| Laser Drilling Hole Size | 4mil(0.1mm) |
| Aspect Ration | 16: 1 |
| Solder Mask | Green, Blue, White, Black, Red, Yellow, Purple, etc. |
| Min Solder mask Bridge | 2mil(0.050mm) |
| Plugged Hole Diameter | 8mil-20mil ( 0.20mm-0.50mm) |
| Beveling | 30° - 45° |
| V-scoring | +/-0.1mm, 15° 30° 45° 60° |
| Impedance Control | ±5% General ± 10% |
| Surface Finishing | HASL, HASL(lead-Free), Immersion Gold |
| Immersion Silver, OSP, Hard Gold ( up to 100u" ) | |
| Certification | UL RoHS ISO9001: 2000 ISO14000: 2004 SGS IAL |
| Testing | Flying probe, E-TEST, X-RAY Inspection, AOI |
| Files | Gerber Protel DXP Auto CAD PADS OrCAD Express PCB etc |
Producing process:
Fast Turn PCB advatage:
1,One stop solution for PCB design, PCB manufacturing and PCBA.
2,Rich experiment for PCB design and manufacturing.
3,Quick turn multi-variety delivery capacity.
4,Perfect internal systerm management.
5,Strong design team.
6,Good service and good qulity.
Trade Terms:
1. We have no MOQ.
2.Payment Term:T/T or Western Union.
2. Delivery ways:UPS,FEDEX,DHL etc,door to door service by sea or air etc.
Application:
1. Consumer electronics.
2. Industrial control.
3. medical instrument.
4. fire service implement etc.
Our Service:
* Engineering Support:
PCB file will be checked by our PCB engineer before manufacturing to avoid any pre-process mistake.
* Customers Service:
Every feedback to our service department will be dealt with in time.
And we can also provide some reasonable suggestions with the pcb files to enhance the competitiveness of product in the markets.
* Full Tracking:
Systematic order process, could check the production status of the entire purchase order. And our we will send you the WIP third times a week for the regular prototype and daily WIP for the quick turn order.
*Standard Packing and On time Delivery
All the outgoing boards will be packaged in the vaccum ESD bay and carton . They are well protected. You can choose whatever delivery service such as Fedex, DHL, UPS or TNT at your convenience.
| PCB Prototype Lead Time: | ||
| item | General time | Quick Turn |
| 1-2 | 4 days | 1 day |
| 4-6 Layers | 6 days | 2 days |
| 8-10 Layers | 8 days | 3 days |
| 12-16 Layers | 12 days | 4days |
| 18-20 Layers | 14 days | 5 days |
| 22-26 Layers | 16 days | 6 days |
| Note: Base on all data received by us and must be complete and problem free, Lead time is ready to ship time. | ||
