Certifications and Factory Pictures
Technical and Capability
. Shenzhen Factory I (Focus on Prototyping, Quick turn, Medium batch)
|Raw material||Aluminum base,Copper base|
|Finished board thickness||0.3-5mm|
|Copper foil thickness||35um-210um(1OZ-6OZ)|
|Remain thicness tolerance||+/-0.1mm|
|Hole position tolerace||+/-0.05mm|
|Routing outline tolerance||+/-0.15mm|
|Punching outline tolerance||+/-0.1mm|
|Surface finished||Lead free HASL,Immersion Gold/Silver,OSP etc|
|MC PCB production capability||10,000 s.q.m/month|
. ShaoGuan Factory II (Mass production& HDI)
|Raw material||FR-4(High TG),CEM-1,CEM-3,Rogers,Teflon etc|
|Min.hole size||0.1mm(drilling hole)|
|Finished board thickness||0.2mm-6.0mm|
|Copper foil thickness||18um-280um(0.5OZ-8OZ)|
|Surface finished||HASL/HASL lead free,Immersion Gold(ENIG)/Tin/Silver,OSP,gold plating/finger,Carbon ink,Peelable mask|
|Impendance Control Tolerance||+/-10%|
|Production capability||50,000 s.q.m/month|
Quality Control Flow:
Pre-Sale and After-Sale Service:
1 Hour quotation
2 hours complaint feedback
7*24 hour technical support
7*24 order service
7*24 hour delivery
7*24 production run
Q1:What's your Aluminum board Thermal Conductivity?
A: Normally 0.8-3W/m.K. If you have special demands please feel free contact us.
Q2:Is my PCB file safe if I send it to you for manufacturing?
A: We respect customer's design authority and will never manufacture PCB for someone else without your permission. NDA is acceptable.
Q3:What is your testing policy and how you control the quality?
A: For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there's many steps to PCB production, we usually do inspection after every step.
Q4: What's your shipping way ?
A: 1. We have our own forwarder to ship goods by DHL, UPS, FEDEX, TNT,EMS.
2. If you have your own forwarder, we can cooperate with them.
Q5: What is your certificate?
A: ISO9001:2008, ISO14001: 2004, UL, SGS,RoHS report.
Q6: What files should we offer?
A: If only need PCB, please provide Gerber File and manufacturing specifications; If need PCBA,Please provide Gerber File, Manufacturing specification, BOM list and Pick & Place/XY file.
Q7: Can I get a sample?
A: Yes, It's reasonable to get a sample to test our quality at first.
Q8: Why choose us?
A: With ABIS, customers significantly and effectively reduce their global procurement costs. Behind each service provided by ABIS, is hidden a cost saving for customers.
. We have two shop together, one is for prototype, quick turn, small volume making. The other is for mass production also for HDI board, with highly skilled professional employees, for high quality products with competitive price and on-time delivery.
. We provide very professional sales, technical and logistic supports, on a world-wide basis.hours complaint feedback
