ELECSOUND is a professional PCB manufactor with 10 years' export experience. Located in Shenzhen, China.
We have skilled and professinal staffs for production line. We can supply FR-4, metal core aluminum based, polyimide, etc. Our PCB factory has obtained ISO 9001 and UL, and we specialize in single, double-sided, 4 layer to 8 layers at a very competitive price with excellent quality. Lead time is 7 to 10 days only.
We produced custom PCBs as below:
4 layers PCB, and multilayer PCB.
We provide different surface finished as customized, such as: HASL lead free, ENIG, hard gold plating, OSP, Rosin, etc.
Files format available as below:
CAM350 Gerber file,
Protel 99 SE
Printed Circuit Board Customized Manufacturing according to Gerber Files or original source file
|Material||FR4, TG130, TG140, TG160, TG170|
|Surface treatment||HASL,Chemical Tin,ENIG(Immersion GOLD),OSP,IMT,Plating silver, GOLD Finger|
|Layers||Single-sided,double-sided,4 layers, 6,8,10,12 Layers|
|Maxi. board size||800mmX508mm|
|Line width/space||0.1mm/ 0.1mm|
|Min.tolerance of Board thickness||+/-8% - 10%|
|Copper foil thickness||Out Layer: 17.5um/35um/70um/105um/140um/175um|
Inner Layer: 17.5um/35um/70um/105um/140um
|Outline Tolerance||CNC routing:+/-0.1mm , Punching: +/-0.1mm|
|PTH hole copper thickness||15um-50um|
|Warp and twist||<=1%|
|Min. registration of hole position||+/-3mil(+/-0.76mm)|
|Min.punching hole||0.8mm(Board thickness below 1.0mm .)|
|Min.Punching Square slot||(Board thickness below 1.0mm, 1.0mmX1.0mm)|
|Registration of printed circuit||+/-0.076mm|
|Min.drill hole diameter||0.2mm|
|Min.tolerance of hole diameter||+/-0.05mm|
|Thickness of surface treatment||Plating Gold:(Ni4um-6um ,Au 0.1um-0.5um),|
Immersion GOLD: (Ni 5um-6um,Au:0.0254um-0.127um),
Plating Silver:(Ag 5um-8um)
|V-CUT degree tolerance||+/-5(degree)|
|V-CUT Board thickness||0.6mm-3.2mm|
|Min.Solder mask width||0.1mm|
|Min.Solder mask ring||0.05mm|
